Carton Erectors | Preferred Pack PP-568 ERT Medium Case Erector (9.8-20inches L x 7.8-15inches W x 4.8-20inches H)
Call Toll Free: 877.336.6877 for Pricing
Availability
Online
In Store
Same Day
Description
Carton Erectors | Preferred Pack PP-568 ERT Medium Case Erector (9.8-20inches L x 7.8-15inches W x 4.8-20inches H)
Once your volume of cases increases it is time to stop hand erecting and taping your boxes.
Our PP-568 ERT Series can erect and tape the bottom of your boxes at up to 12 cases per minute.
FEATURES
ERT: Carton Erector - Vertical Style
- ML: Medium size for Left side exit
- For all general type of corrugated boxes
Mechanical Aspect:
- Vertical seal
- Belt driven with universal bearing
- Double suction arm
- Aluminum frame and acrylic safety fence
- Easy maintenance
SPECIFICATIONS
- Power Supply 3 Phase, 220/380/415/440V
- Air supply 6kgf/cm (137.64L/min.)
- Tape Head C-1
- OPP 2inches/3inches (Please advise when ordering)
- Sealing Size:(LxWxH) 2inchesOPP:250~510 x 200~380 x 120~500 / 3inchesOPP: 250~510 x 225~380 x 120~500
- Tape Overlap: 2inches OPP: 60±5 / 3inches OPP: 40±5
- Working Table Height:25inches
- Capacity 9~12 boxes/min.
- Net Weight: 1808 lbs
- Machine Size:(LxWxH) 99inches x 93inches x 61inches
OPTION
Mechatronic Aspect:
- HMI touch panel
- Detection for failed box folding
- Detection for low boxes
- PLC system
Mechanical Aspect:
- Right Hand or Left Hand performance
- Safety Fence: aluminum frame with acrylic window panel
System Aspects:
- Combine with case strapper to secure your package even more.
Special Needs:
- Stainless steel structure SUS# 304
Preferred Pack PP-568 ERT Case Erector
COVID Supply Chain Warning Due to global challenges including COVID and Climate Change affecting all businesses, prices are subject to change because of supply chain disruptions, shipping delays, labor shortages, material shortages, and inflationary pressures. If you place an order, and there is an increase in a price from that shown, we will alert you before processing the order.
Specifications
| Dimensions (LxWxH): | 99.00in. x 93.00in. x 61.00in. |
SPECIFICATIONS
| |
