Description

Side Seal Machine | PP-5545TBH Entry Level Intermittent Motion Side Seal Machines

2-Belt fully automatic, infinite length, side seal machines will seal all commercially available polyolefin and polyethylene films. 2 belt design provides for smooth product transition from infeed belt to side seal, then through cross seal bar. Omron Inverter Drives with Variable Speed Drive 0 to 1 00 FPM.

FEATURES

• Omron PLC
• Teflon Coated Hot knife Cross Seal Bar
• Servo Motor Drive on Cross Seal
• Independent digital temperature controls
• Omron Color Touch Screen
• Motorized scrap wind up wheel with built in alarm when full
• Emergency stop switch with reset button
• Automatic pin wheel hole punch
• Powered in-feed conveyor with electric eye to start cycle
• Adjustments for bag size front and back
• Rear mounted film carriage
• Accepts random length products with no changeover required
• Adjustable height legs with locking casters
• Fully enclosed seal area
• Safety interlocks on all doors

SPECIFICATIONS

• Seal Area:18 Inches (457.2 MM)Cross Seal x 6 H Inches (152.4 mm)
• Min Pkg Size :15 Inches (381 mm) W x 6 L Inches (152.4 mm)
• Speed : 40-60 PPM
• Electrical: 110/220 Volt, 1 phase
• Air: 3-4 CFM at 80 PSI
• Power:3kw (3000 watts)
• Cross Seal Width:17.7 INCHES (450 MM)
• Net Weight:800kg (1,760 Lbs)
• Machine Dimensions:80 L x 58 W x 51 H INCHES (2032 x 1473.2 x 1295.4 MM)
• Warranty:1 year on all parts
