Vacuum Packaging | Excel T3500G Touchscreen Vacuum Sealers with Gas Purge

Place you new T3500G Touchscreen Vacuum Sealers wikth Gas Purge Sealer on a work table.Connect a 1/4 Inch O.D. Plastic tubing to the Push-in fitting on back Of the Machine labeled AIR and supply clean dry Compressed Air between 80 and 100 PSI.if you use the Gas purge option, Connect a 1/4 Inch O.D. Plastic tubing to the Push-in fitting on back of the Machine labeled GAS and supply an inert Gas at low pressure between 35 and 60 PSI.Insert the electrical plug to a 110/120 VAC. Or a 220/240 VAC

Standard Features:

• Cleanroom Compatible
• Touch Screen Controls
• 5 Bag Preset Menu & Multiple Programs
• Vacuum Gauge
• Stainless Steel Retracting Nozzle
• Gas Purge
• No Pinch Safety Jaw
• Overheat Protection
• Electronic Foot Switch
• Fast All Digital Electronics
• Advanced Safety Controls
• Air Supply Required

Options:

• 4 Position Table Top Stand
• Seal Only Switch ( for impulse seal no Vacuum )
• Vacuum Filter ( for Packing with Liquids )
• Dual Nozzle ( for faster Packaging )
• International Voltages ( 220/240 AC or 100 AC )

SPECIFICATIONS

• SEAL LENGTH :35 Inches (889 mm)
• TYPE :Vacuum Sealer with Touch Screen & Gas Purge
• AIR Consumption : 5 CFM @ 90 PSI
• Voltage : 120 VOLTS
• Dimensions : Seal + 6 L x 12 W x 8 1/2 H INCHES (153 x 305 x 216)
• Machine Weight : 52 LBS
