Inkjet Printers | Preferred Pack MacroCode Large Character DOD Inkjet Printer

MACROCODE DROP ON DEMAND PRINTING SYSTEM

When a small printhead meets large, clear dots and easy operation, you get reliable DOD (Drop on Demand) coding from InkJet, Inc.’s MacroCode. MacroCode has the fastest print speed at 575 ft/min, capable of water-base or solvent printing, a 7” color touch screen, stainless steel ink container, auto flushing system and optional IP65 configuration.

CLEAR, FAST & RELIABLE

The MacroCode large character DOD inkjet printing system tackles various applications with ease. The design of the printer includes a large 7” graphic LCD touch screen, dialogue menu with font reduction mode, capable of achieving flexible, fine marking within 12~63mm. It is available for fast drying ink on either porous or non-porous substrates, making it ideal for any printing application where large readable characters are needed.

The robust, compact design and structure is built for any environment. It is designed to install easily with minimal mounting. Each printhead has two lines for ink transfer. A single line for ink supply, and an additional line for ink return, enabling the printhead to recycle ink and perform auto flushes, minimizing maintenance and down time.

The controller for the MacroCode system utilizes a Window-based graphic user interface to help users navigate and operate the system with ease. The 7” color touch screen provides an adequate size interface, while keeping the controller compact, minimizing footprint. The software menu is available in a variety of languages if needed.

MacroCode has three nozzle sizes, 7, 16 and 32 and is available for both water based and solvent based inks. InkJet has a complete line of water based and solvent based inks for all of your large character printing needs.

SPECIFICATIONS

• PRINT SPEED :SOLVENT Type: Max. 575 ft/min, WATER BASE Type: Max. 410 ft/min
• PRINT HEIGHT :SOLVENT, 7 nozzles: Max. 26 mm, 16 nozzles: Max. 63 mm, 32 nozzles: Max. 130 mm. WATER BASE, 7 nozzles: Max. 14 or 24 mm, 16 nozzles: Max. 33 or 60 mm, 32 nozzles: Max. 68 or 124 mm
• FONT REDUCTION : Adjustable with the tilt bracket
• AVAILABLE LANGUAGES : English, Chinese, Korean, Japanese, Vietnamese, Italian, Turkish, Spanish, Arabic, Persian, Portuguese, Lithuanian, German, French, Russian, Dutch, Indonesian, Hindi, Malaysia, Bangla, Thai, Rumanian
• STORAGE CAPACITY : 1,000 messages
• MESSAGE : Text, Barcode, Image, Auto Date/Time, Counter, Shift
• BARCODE : DataMatrix, CODE128, CODE39, CODE93, CODE2OF5, EAN13, UPCA, UPCE
• FONT TYPE : Gulim, Arial or Importing of an external font
• DATE TYPE : Production Date, Expiration Date, Julian Date
• WAVE UTILITY BRACKET :Printing on uneven surfaces such as PP bag
• OPERATING TEMPERATURE :5°-45° C
• DISPLAY : 7 Inch (800 X 480 mm) Color LCD Touch Screen
• POWER : AC120V-240V / 50-60Hz
• INK REFILL : Available with or without Safety Ink Refill with NFC Tag
• CONNECTION PORT : Photo Sensor, Warning Light, BCD, RS232, Encoder, USB
• BACKUP/RECOVERY : USB
• NOZZLE PITCH : SOLVENT: 4.2 mm / WATER BASE: 2.2 or 4.0 mm
• CERTIFICATE : CE, FCC
• INK SUPPLY : 2.5L Stainless Steel Ink Container (Other size options: 1L, 5L, 14L)
• INK OR CLEANER FLUSH : Solvent or Pigment Auto Flushing System (optional)
• NFC TAG : NFC Tag Ink Refill with Floating Level Sensor (optional)
• INK TYPE : MEK, Water, Ethanol, Alcohol, Pigment, MEK-Free, Food-grade, UV Invisible
• INK COLORS : Black, Red, Blue, Green, White, Yellow, Orange, Violet
• SUBSTRATES : Carton Boxes, Paper Bags, Vinyl, Stainless Steel, Pipe, Aluminum, PP Bags, PVC, etc.
