Description

SUNPACK WK02-30B Strapping Banding Machine FloorModel

When making your purchase of this item, consider that we carry all parts for this SUNPACK Banding Machine and offer you support! We are in the USA, and you can easily reach us by CHAT, E-mail, Fax, and Telephone. See if our competitors can make those same statements. Most of them do not and cannot.

Banding machines have been a cost and labor-saving solution for many industries worldwide, such as pharmacy, printing, graphics, dairy products, and currency. This banding machine uses a heat sealing system to bond the material to form a tidy seal around the item.

FEATURES

• Tape Material: Paper or OPP film
• Strapping Speed: 3 seconds or less
• Tension: 5~40N
• Package Dimensions: Min: 1.2 x.39 Inch (30 x 10 mm) / Max: 18.1 x 7.9 Inch (460 x 200 mm)
• Machine Dimensions: 24.8 x 14.33 x 48.7 Inch (630 x 364 x 1239 mm) LxWxH
• Power Supply: 220V 50hz 1phase or 110V 60hz 1phase
• Net Weight: 74.5 kg (164.24 lbs)
• 60 Seconds Pre-Heating time
• Heat Sealing
• Applicable for both paper band and OPP film
• AC motor Power

Strapping-Banding-Machine TableTop-Mode

SUNPACK WK02-30 Automatic Table Top Strapping Banding Machine

Specification

• Tape Specification:
  • Width: 19.2-19.6 mm (075 - 0.77 In),
  • Thickness: 120 mic,
  • Length: 500 meters.
  • Banding Roll Core: 40 mm (1.57 In)
• Arch Size: 470*200 mm (18.50*7.87 In)
• Table Height: 980 mm (38.60 Inch)
• Power Supply: 220V 50hz 1phase or 110V 60hz 1phase
• Power Rate: 160W
• Control System: PCB+Key board control panel
• Banding Speed: 25 bands/Minute
• Banding Tension: 5-40N
• Welding Method: Heat Sealing
• Net Weight: 72kg (159 lbs)
• Machine Dimension: L 611 x W 364 x H 1175 mm (L24 x W14.33 x H 46 In)

Common Replacement Parts for SUNPACK WK02 Banding Machine Models

Replacement Spring Washer (Part# WK01-14-20-02-v1)
Replacement Top Sliding Plate (Part WK01-14-26-01-v3)
Replacement Sliding Wheel (Part# WK01-14-26-03-V1)
Replacement Inner Spring Washer (Part# WK01-14-20-02-V2)
Replacement Heater Unit Assembly (Part # WK01-14-16)
Replacement Cutter (Part # WK01-14-16-01-V2)
Replacement Front Knife Unit (Part # WK01-14-17)
Replacement Top Plate Unit (Part # WK01-14-26)
Replacement Siding Plate Unit (Part # WK02-14-27)
Replacement Approximate Switch (Part # FL7M-3J6HD)
Replacement Micro Switch (Part # E42AL-BA12AG-01 GREY)
Replacement Photocell (Part # PM2-LH10-C1)
Replacement Reel Core (Part # WK01-11-05-V1)
Replacement Big Transformer (Part # 220/1.4V 45VA)
Replacement Heating Cable (Part # 610 280)
Replacement Feeding Wheel (Part # WK02-14-19-01)
Replacement Heater (Part # WK01-14-16-05)
Replacement Insulating Plate (Part # WK01-14-16-06)
Replacement Insulating Plate (Part # WK01-14-16-02)
Replacement Insulating Plate (Part # WK01-14-16-04)
Replacement Driven Wheel (Part # WK01-14-08-08)
Replacement Feeding Guide Unit (Part # WK02-14-18-00)
Replacement Arch Unit 4620 (Part # WK02-30-03U)

Demo Video

If you have any questions or concerns, contact a customer service representative today.
Phone: 877.336.6877 Visit: www.officeequipmentmachineshop.com
