Description

Pallet Stretch Wrapper Preferred Pack PP-4505A (High Profile - No Ramp) “Fully Automatic” Pallet Stretch Wrapping Machine with “Cut, Clamp and Wipe"

The Model PP-4505A (High Profile-No Ramp) is a “Fully Automatic” Pallet Stretch Wrapping Machine with “Cut, Clamp, and Wipe.” Load the pallet onto the turntable and press the start button on the “REMOTE Control,” and the machine does the rest. The forklift operator never has to take the time to get off the forklift and back on again, a true time saver which allows the operator to process many more loads per hour than a conventional turntable pallet wrapper. The PP-4505A features power pre-stretch at 250% stretch for increased film yields. Rated for up to 30-40 loads per hour.

FEATURES

• Powered pre-stretch with easy load design and smooth film delivery,
• 250% powered pre-stretch for increased film yields and film cost savings makes machine ROI easy to achieve; A 5,000 ft roll of machine film turns into 17,500 ft of film applied to the load at 250% stretch. (Optional 300% pre-stretch available)
• Patented powered pre-stretch system design with easy thread film loading.
• Safety door-Must be closed for pre-stretch to work;
• Automatic “Cut and Clamp” machine will automatically clamp the film and attach it to the load;
• Automatic “Cut and Wipe” will automatically cut the film once the load is wrapped and wipe the excess down against the load.
• Soft start and stop turntable for unstable loads;
• Film core diameter is 3”
• Max film roll diameter is 9.8”
• HMI Control Touch Panel easily adjusts top and bottom wrap counts, turntable speed, and carriage speed;
• PLC control system;
• Program the top and bottom wrap count from HMI;
• Independent film tension control, which allows an operator to apply film to the load lightly or very tight, turntable speed and film carriage speed controls all accessed through the HMI touch screen;
• Heavy duty drive chain for film carriage;
• Easy to install mast with bottom pivot bolts, raise the mast and attach the bolts;
• AC motor inverters with PLC control system, easy to use and very reliable;
• Photo Eye-Automatically seek pallet load height up to 85” for the standard wrapper (Optional 98” tall mast available)
• 110 Volt, 10 amp, plugs into a regular wall outlet;
• Variable Speed Turntable 0 to 12 RPM
• Turntable diameter of 65”;
• Height of turntable 4.3”
• Rated at up to 30 to 40 loads per hour
• 4,400 Lbs load capacity;
• Max load size 40” x 48” x 85”
• Maximum Diagonal 61.5”
• Home Position – The turntable always returns to its original position.
• Forklift Portable-Forklift access from the Front or Back of the machine, easy to move around;
• Heavy duty 1 HP turntable drive motor;
• Heavy duty #50 drive chain for turntable;
• “Wireless” Remote Controls-Allows operator to start the machine with remote control without getting off the forklift (set of 2)
• Your pallet stretch wrapper comes fully crated for maximum protection during transport. The mast is lowered to reduce the profile of the shipment.
• Manufactured to CE certification standards.
• Emergency Stop Switch;

SPECIFICATIONS

• Electrical : 120 Volt, 1 phase, 10 amp
• Air: 1 CFM at 60 PSI
• Warranty : 1 year limited warranty on parts from date of delivery
• Machine Dims : 98 L x 60 W x 102 H Inch
• Crated Dimensions : 111” L x 70” W x 40” H Inch
• Weight : Net:1,450 Lbs / Gross: 2,486

DEMO VIDEO
