Description

Foam Strip Adhesive - High-Temperature Tolerant Double-Sided Tape Part # TS1531016

This will adhere Foam Strips to the Rubber Diaphragm.

How much tape is required to replace the foam strips on a 4468H Vacuum Press?

Generally, one roll per diaphragm, if used correctly, as it takes two (2) strips (3/4” width), side by side to give 1 and ½” around the perimeter of the board to apply the foam strips to, and then one strip across the top of the foam to attach the rubber to top of foam.
It will take roughly 1 ½ rolls to accomplish the same thing on a 5298H Vacuum Press.
We recommend using 3M product numbers 926 or 969, as both are high-temperature tape ¾” wide. We’ve used both in manufacturing; the 969 is just a little more aggressive.

Description

High Temperature Tolerant Double Sided Tape

Part # TS1531016

D and K Replacement Parts for Dry Mount Press 3648H/2180

**Click on the links below to go to the item page for the parts.**

Heater - TS2302105 for Dry Mount Press 3648H
Vent Cloth - TS5214012 for Dry Mount Press 3648H
Diaphragm Assembly - TS6299118 for Dry Mount Press 3648H
Foam Strips Front/Back - Long: Individual Strip - TS2205053 for Dry Mount Press 3648H
Foam Strips Sides - Short: Individual Strip - TS2205054 for Dry Mount Press 3648H

D and K Replacement Parts for Dry Mount Press 4468H/2160

**Click on the links below to go to the item page for the parts.**

Heater - TS2302089 for Dry Mount Press 4468H
Vent Cloth - TS5214008 for Dry Mount Press 4468H
Diaphragm Assembly- TS6299114KIT for Dry Mount Press 4468H
Top Cover - TS6201142KIT for Dry Mount Press 4468H
Platen Kit - TS5612019 for Dry Mount Press 4468H
Formica/Honey Comb - TS5704014KIT for Dry Mount Press 4468H
Foam Strips Front/Back - Long: Individual Strip - TS2205045 for Dry Mount Press 4468H
Foam Strips Sides - Short: Individual Strip - TS2205046 for Dry Mount Press 4468H
Ceramic #8 Wire Nut - Heater - TS1221008 for Dry Mount Press 4468H
Top Insulation, 3 Pcs - Ea Piece - TS511009 for Dry Mount Press 4468H

D and K Replacement Parts for Dry Mount Press 5298H/2170

**Click on the links below to go to the item page for the parts.**

Gas Spring - TS1124014 for Dry Mount Press 5298H
Solid State Relay - TS1306028KIT for Dry Mount Press 5298H
30 Amp Breaker Switch- TS1308061 for Dry Mount Press 5298H
Center Heater - TS2302096 for Dry Mount Press 5298H
Right Heater - TS2302097 for Dry Mount Press 5298H
Vent Cloth - TS5214011 for Dry Mount Press 5298H
Sensor Assembly - TS6208077 for Dry Mount Press 5298H
Diaphragm Assembly - TS6299130KIT for Dry Mount Press 5298H
Platen - TS5612026E for Dry Mount Press 5298H
Foam Strips Sides - TS2205051 for Dry Mount Press 5298H
Foam Strips Front/Back - TS2205052 for Dry Mount Press 5298H
Wiring Harness - TS2205053 for Dry Mount Press 5298H
Foot Plugs Center Legs - TS4016007 for Dry Mount Press 5298H

D and K Replacement Parts for Dry Mount Press 3444H

**Click on the links below to go to the item page for the parts.**

Tracking Iron Outlet - TS110S024 for Dry Mount Press 3444H
Accessory Plug-Pump - TS12020S2 for Dry Mount Press 3444H
Ribbon Cable - TSS304026 for Dry Mount Press 3444H
Sensor Assembly - TS6208075 for Dry Mount Press 3444H
Diaphrgm Assembly - TS6299116KIT for Dry Mount Press 3444H
Gas Springs - TS1124010 for Dry Mount Press 3444H
Vent Cloth - TS5214009 for Dry Mount Press 3444H
Foam Strips Front/Back - TS220S046 for Dry Mount Press 3444H
Foam Strip Sides - TS2205048 for Dry Mount Press 3444H

Common Parts for D and K Replacement Parts for Dry Mount Press 3648H/2180, 4468H/2160, 5298H/2170 and 3444H

**Click on the links below to go to the item page for the parts.**

Tracking Iron Bolt Outlet - TS1105024 for Dry Mount Press 3648H, 4468H and 5298H
Solenoid - TS1122087 for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Pump Elbow - TS1122092 for Dry Mount Press 3648H, 4468H and 5298H
Side Latch - TS1123013 for Dry Mount Press 3648H, 4468H and 5298H
Gas Spring - TS1124013 for Dry Mount Press 3648H, 4468H and 5298H
Accessory Plug - Pump - TS1202052 for Dry Mount Press 3648H, 4468H and 5298H
Solid State Relay - TS1306026KIT for Dry Mount Press 3648H, 4468H and 5298H
20AMP Breaker Switch - TS1308041 for Dry Mount Press 3648H, 4468H and 5298H
Conduit Strain Relief - TS1106047 for Dry Mount Press 3648H, 4468H and 5298H
Power Board - TS2304092 for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Power/Control Board - TS2304093 for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Hinge Screw - TS40030 for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Ribbon Cable - TS5304026 for Dry Mount Press 3648H, 4468H and 5298H
Sensor Assembly - TS6208075 for Dry Mount Press 3648H, 4468H and 5298H
Current Pump - Thomas - TS6299126KIT for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Side Latch Retrofit Kit - TS6299139 for Dry Mount Press 3444H, 3648H, 4468H and 5298H
Wiring Harness - TS5304027 for Dry Mount Press 3648H and 4468H
Ball Studs - TS1068010 for Dry Mount Press 3648H, 4468H and 5298H
Leveling Feet - TS1103010 for Dry Mount Press 3648H, 4468H and 5298H
C-Clips - TS1126015 for Dry Mount Press 3648H, 4468H and 5298H
Manifolds - TS5099023 for Dry Mount Press 3648H, 4468H and 5298H
Conduit Connectors - TS1106046 for Dry Mount Press 3648H, 4468H and 5298H

If you have any questions or concerns, contact a customer service representative today.
