Description

D and K Masterpiece 210M Expression Mechanical Press w/o digital control with 18.5 x 23 Inches Workspace

The Expression® (EXP) 210 Mechanical Press is designed to provide consistent heat and uniform pressure for mounting, laminating, or texturing large items including photos, plaques, and artwork. The 210 Mechanical Press features an easy-to-use temperature control knob for setting adjustments. The 210 Mechanical Press is a dependable workhorse designed to process large pieces up to 36 Inches wide by any length.

The quality features engineered into the larger model are also available in compact machines with a smaller footprint and a working space of 18.5 x 23 Inches

**A LIST OF 210M REPLACEMENT PARTS WITH LINKS IS ON THE LOWER PORTION OF THIS PAGE. **

D & K Expression Mechanical Press Features

• Designed to consistently provide even heat and uniform pressure - two of the most important requirements for quality mounting and laminating.
• Temperature control knob
• Simple controls for easy operation and professional results.
• Capable of finishing pieces even larger than the press itself.
• Durable framework, built-to-Iast construction.
• Easy-to-c1ean platen surfaces.
• Made in the USA
• Presses are UL Listed and CUL Approved.

SPECIFICATIONS

• Capacity:18.5 x 23 Inch (47 x 58 cm) 36 Inch (91 cm) by any length in sections
• Dimensions:27 W x 23 D x 11 H Inch (69 x 58 x 28 cm) 20 in. (51 em) high open
• Shipping Weight : 75 lb. (34 kg)
• Power Requirements : 115 VAC, 11.3 Amp (230V AC, 5.7 Amp)*

D and K Replacement Parts for Dry Mount Press 210M and 210MX

**Click on the links below to go to the item page for the parts.**

Tai Rod - TS100449-02 for Dry Mount Press 210M
Face Plate - TS15-4801 for Dry Mount Press 210M
Heater Kit - TS6299013 for Dry Mount Press 210M and 210MX
Pressure Board - TS140150 for Dry Mount Press 210M and 210MX

Common Parts for D and K Replacement Parts for Dry Mount Press DS100, 160M, 210M, 210MX, 250, 500T and 500TX

**Click on the links below to go to the item page for the parts.**

Toggel Nut - TS100590 for Dry Mount Press DS100, 160M, 210M
Thermostat Kit - TS100897KIT for Dry Mount Press 160M and 210M
On/Off Switch - TS1302053KIT for Dry Mount Press DS100, 160M, 210M
Sponge Pad - TS143222 for Dry Mount Press 210M, 210MX, 250
Porcelain Wire Nuts - TS18005 for Dry Mount Press DS100, 160M and 210M
Electrical Kit - TS6299038 for Dry Mount Press 160M and 210M
Thermometer Kit - TS6299011 for Dry Mount Press 160M, 210M, 210MX, 500TX and 500T
Platen Kit - TS6299019 for Dry Mount Press 210M, 210MX, 250
Foot Kit - TS6299022 for Dry Mount Press 110S/168, 160M/1400, 210M/1403, 210MX/1407 and 250
Toggle Plate Bolt Kit - TS6299024 for Dry Mount Press 160M, 210M, 210MX and 250
Pressure Adjustment Kit - TS6299033 for Dry Mount Press 160M and DS100
Handle Kit - TS6299029 for Dry Mount Press 210M, 210MX, 250
Pressure Adjustment Kit - TS6299032 for Dry Mount Press 210M, 210MX,,250
Thermostat Knob Kit - TS6299010 for Dry Mount Press 160M, 210M, 500T, and DS100
Pressure Board - TS130141 for Dry Mount Press 160M and DS100

If you have any questions or concerns, contact a customer service representative today.
Phone: 877.336.6877 Visit: www.officeequipmentmachineshop.com
